WARN윈치 VR12000 - Jeep 전차종 요약정보 및 구매

상품코드 : 1447796596

제조사 WARN
모델 WARN VR12000 Winch
판매가격 1,890,000원
배송비결제 주문시 결제

상품의 재고가 부족하여 구매할 수 없습니다.

상품 상세설명









WARN 원사 VR 12000 윈치

Jeep 전차종






















VR12000 SPECS/PART NUMBERS
Part Numbers: PN 86260 (12V DC)
Rated Line Pull: 12000 lbs. (5443 kgs.) single-line
Motor: 12V DC, Series Wound™
Electrical Controls: Solenoid
Remote Control: Remote switch, 12" (3.7m) Lead
Geartrain: 3-Stage Planetary
Gear Ratio: 216:1
Clutch (freespooling): Sliding Ring Gear
Brake: Automatic Direct Drive Cone
Drum Diameter/Length: 2.5"/9.0" (6.4cm/23cm)
Weight (kit shipping): 89 lbs. (40.4 kgs.)
Wire Rope: 3/8" x 94' (9.5mm x 28.6m)
Fairlead: Roller
Recommended Battery: 650 CCA for winching
Battery Leads: 2 gauge, 72" (1.83m)
Finish: Powder coat over primer undercoating
Warranty: Limited Lifetime

12V DC PERFORMANCE SPECS
Line Pull
Lbs.(Kgs.)		 Line Speed
FT./min(M/min.)		 Motor
Current		 Pull by layer
layer/Lbs(Kgs.)
0 28.4 (8.6) 65 amps 1/12000(5443)
2000(910) 12.6 (3.8) 144 amps 2/111200(5044)
4000(1810) 9.5 (2.8) 215 amps 3/10340 (4690)
6000(2720) 7.5 (2.2) 281 amps 4/9770 (4432)
8000(3630) 5.8 (1.7) 349 amps 5/9250 (4196)
10000(4540) 4.4 (1.3)) 415 amps
12000(5440) 3.6 (1.0) 457 amps



Winch Dimensions: 21.83" L. x 6.3" D. x 6.97" H.
(554mm L. x 160mm D. x 177mm H.)
Mounting Bolt Pattern: 10.0" x 4.5"
(254mm x 114.3mm)



Parts Included

  • VR12000lb Winch
  • Control Pack
  • 94’ of 3/8” (28.6m of 8mm) diameter wire rope with Hook
  • Roller Fairlead
